Utra Small Size Metallized Polyester Film Capacitor 223J50V LS 5mm

Features

• Ultra-small, low noise, good appearance consistency.
• Metallized polyester film, small inherent temperature rise.
• High voltage resistance, high temperature wax sealed, flame retardant epoxy powder coating.
• Moisture-proof, flame retardant.
• Low dissipation factor.
• Good self-healing property, good stability and reliability

Configuration

Coiled with dielectrics and electrodes made of metallized polyester films, conducting cp wire down-leads in a single direction. Rectangular enclosure adopts self-extinguishing plastics and encapsulated with antiflaming araldite.

Product Application:

This kind of utra small size capacitor could be used in DC and low pulse occasions, for power amplifier, color TV, communication equipment, power supply, LED driver and other circuits requiring small size.

Specifications:

Referance Standard		GB7335-87
Climatic Category		40/100/21
Rated Voltage		50V
Capacitance Range		0.022uF
Capacitance Tolerance		±5%(J)
Voltage proof		1.6UR(5s)
Dissipation Factor		≤0.1%(20℃, 1KHz)
Insulation Resistance		≥75000MΩ (CR≤ 0.33 uF) ≥2500S (CR>0.33 uF)

Packing:
Bulk, Ammo, T&R

OUTSIDE MARKS FOR CAPACITANCE:

FAQ Of Topmay Capacitor

1) Can I have a free sample to test ?
Yes, we could provide free samples to test and check quality. Freight cost is collected.

2) What is the lead time?
Sample needs about 7~10 working days prepared; mass production average time takes 15-20 working days

3) Do you have any MOQ limit?
Yes. But it depends on product. Normally MOQ is 2K~10Kpcs

4) How about price terms?

We do FOBSHENZHEN if order amount is more than 5000USD. Less than that, it is EXWSHENZHEN and we do not undertake local charge.

5) What information should I let you know if I want to get a quotation?

Basically for capacitor, it requires to know detailed capacitance and voltage. If you have more information, such as type, product photo for reference, you could kindly provide too.
