Axial Leaded Multilayer Ceramic Capacitor Color Code Mono Capacitor
100nF 50V 0805 X7R
Feature
- Large capacitance, small volume
- High reliability, stable capacitance
- High temperature and moisture resistance
Application: Widely used in electronic precision instruments. All kinds of
small electronic equipment for resonance, coupling, filtering,
bypass.
General Specification
| A | Product Type | B |
Nominal Body Size(Length ×Width±0.05) |
| TMCC06 |
Class 1 Color Code Axial lead ceramic capacitor | 0805 | 2.0×1.25mm |
| C |
Temperature Characteristic | D |
Nominal Capacitance C |
| X7R | ±15% | -55～+125℃ | 104 | 100nF |
| E |
Tolerance | F |
Rated Voltage |
| K | ±10% | 50V |
| G |
Packaging Style | H |
Lead length(Unit:mm) |
| Blank |
5000pcs/ Taped Box | P52 | 52mm |
| I |
Wire material |
Specifications |
Wire diameter |
Line conductivity |
Tin plated copper clad steel wire | Φ0.45~0.5mm | 16.6% (±0.5) |
Tin plated copper wire | | |
Dielectric Charateristics
| ITEM | TEST STANDARD |
| NPO ( N ) | X7R ( B ) | Y5U , Y5V ( Y ) |
| Capacitance | WITHIN THE TOLERANCE | WITHIN THE TOLERANCE | WITHIN THE TOLERANCE |
| Dissipation Factor |
≤0.15% |
≤3.5% |
≤7%(less than 220nF )
≤10% ( 220~470nF )
≤15% ( 470~1000nF ) |
| Insulation Resistance | C≤10NF IR>10000MΩ
C>10NF R .C>100S | C≤25NF IR>4000MΩ
C>25 NF R.C>100S |
Voltage Test | Test voltage:2.5.rated voltage
The charging current may not exceed 50 mA. Duration of test:5
seconds |
| TEST CONDITION |
| FREQUENCY | 1M HZ
(C>1000PF,1KHZ) | 1KHZ |
| T EST VOLTAGE | 1VDC | 0.5 VDC |
| TEST VOLTAGE OF IR | The measuring voltage is equal to the rated voltage.
The charging current may not exceed 50 mA |
| Standard atmospheres conditions | Unless otherwise specified, the standard range of atmospheric
conditions for measuring and testing is as follows:
Ambient temperature 15 °C ~35 °C
Relative humidity 45%~75%
Air pressure 86Kpa~106Kpa (860-1060mbar)
If there may be any doubt on the results, measurements shall be
made within the following limits:
Ambient temperature 25 °C ±1 °C
Relative humidity 48%~52%
Air pressure 86Kpa~106Kpa (860-1060mbar) |
| Operating temperature range | The operating temperature range is the range of ambient
temperatures at which the capacitor can be operated continuously at
rated voltage.
Temperature compensation use:
NPO -55 °C ~+125 °C
X7R -55 °C ~+125 °C
Y5V -25 °C ~+85 °C
Z5U +10 °C ~+85 °C |
Color Code
Black 0, brown 1, red 2, orange 3, yellow 4, green 5, blue 6,
purple 7, gray 8, white 9.
The color ring value is readed in the same way as resistor. The
first two digits are the number, and the the last digit is multiple
of 10.
For example, if the colour ring is red, red and yellow, then
224=22×10⁴=0.22μF
Color Code
Packing
Bulk or Tape
Our series of strong products of capacitors can be divided into
below types:
★ Ceramic Disc Capacitor( low and high voltage, Y1/Y2 safety )
★ Multilayer Ceramic Capacitor( radial, axial and SMD )
★ Film Capacitor( Mylar, MKT, MKP, X2, CBB60, CBB61, CBB65,
CL21-Box, CBB-BOX, CL20, CBB20, CBB81, etc. )
★ Aluminum Electrolytic Capacitor(SMD, Radial , Axial, Snap-in ,
Screw Terminal, etc. )
★ Tantalum Capacitor(SMD, Radial , Axial )
★ Super Capacitor( Coin Type, Cylindrical Type, Module Type)
★ Mica Capacitor
★ Trimmer Capacitor
And series of resistors which we develop new production lines are
as below:
★ SMD Resistors
★DIP TYPE Resistors( KNP, CF, MF, MOF, ect,)
★ Cement Resistors
★ Leadless Resistors( MLEF)
★Power Resistor
More details, kindly contact us freely!
